Product Title:
Worldwide Certificates 24V Lithium Battery Charger 29.4V 10A Charger

Product Description:
High Quality 24V 10A Lithium Battery Charger 29.4V 10A Lithium Charger | 29.4V 10A Lithium Battery Charger

The Henryuan 29.4V 10A Lithium Battery Charger offers top level charging performance for a variety of 24V lithium-ion battery applications. With UL, PSE, CE, EMC, LVD, SAA, and FCC certifications, this charger is built to meet the highest safety standards globally, ensuring safe and efficient charging.

Charging Stages:

Constant Current: 10A fast charging, voltage 17.5V -29.4V, LED red.

Constant Voltage: 29.4V max, current 10A to 1A, LED red.

 Trickle Current: 1A to 0, voltage 29.4V max, LED green.

Charging Curve:
The 29.4V 10A lithium charger maintains a consistent and efficient charging curve, preserving battery health.

Compact and Portable Design

• Its lightweight and compact design makes it easy to carry and store,but large power
• Dimensions: 176 x 80 x 47 MM
• Weight: 0.5kg

• Experienced Sales Engineers: Over a decade of expertise in understanding and meeting customer needs.
• Rigorous Material Selection: Only top-quality raw materials are used.
• Strict Inspection Process: Comprehensive incoming material inspections ensure quality.
• Expert Engineers: More than 20 years of design experience.
• Skilled Production Team: Advanced production and testing equipment.
• Aging Testing: 100% aging testing process, up to 4 hours at full load.
• Comprehensive After-Sales Support: Feedback and resolution within 48 hours.

About Henryuan Group:

With over 13 years of experience in the production and R&D of 24V lithium battery chargers, Henryuan Group is a leading industry supplier. Our 29.4V 10A lithium battery chargers are globally recognized for their superior performance and safety features. Exported to the Americas, Europe, the UK, Australia, New Zealand, and Asia, they are trusted by consumers worldwide for a variety of applications.

Henryuan 24V Lithium Battery Charger Range:

Various 29.4V lithium battery chargers with currents 0.5A, 1A, 1.5A, 2A, 2.5A, 3A, 3.5A, 4A, 5A, 6A, 6.5A, 7A, 8A, 9A, 10A.

More 29.4V Lithium Battery Charger Links:

• Explore More 29.4V Lithium Battery Chargers.

Contact Us:

For a safe, reliable, and efficient 29.4V 10A lithium battery charger, contact Henryuan's expert sales engineers today.
Q&A:

Q1: Is this 29.4V 10A charger compatible with a standard 24V lithium-ion battery pack?

A: Yes, it is custom-engineered for standard 24V packs. In the industry, a "24V lithium battery" typically refers to a 7S (7 cells in series) lithium-ion configuration with a nominal voltage of 25.2V or 25.9V. However, its true fully-charged voltage must reach exactly 29.4V. This 300W charger utilizes a precise CC-CV (Constant Current - Constant Voltage) profile to safely and efficiently bring your 24V pack to 100% full capacity.

Q2: How fast can a 10A output charge an industrial 24V battery pack?

A: The 10A high-current output delivers commercial-grade fast charging designed to minimize equipment downtime. You can project the active charging window using this standard industry calculation:

• For a 40Ah industrial battery pack: about 4.8 hours for a safe, complete charge.

• For a 20Ah e-mobility battery pack: about 2.4 hours from empty to ready.

Q3: How does the 3-stage charging profile safely manage heat and power termination under a heavy 10A load?

A: Thermal and electrical stability are controlled via an integrated switching circuit operating across three distinct phases:

• Stage 1 (Constant Current): The charger drives a full, steady 10A bulk charge into the battery. The LED remains Red.

• Stage 2 (Constant Voltage): The voltage is locked at a strict 29.4V while the current naturally tapers down as the chemical cells saturate,the LED remains Red.

• Stage 3 (Trickle Current Stage): The moment the saturation current drops below a pre-set engineering threshold 1.0A, the LED flips to Green, signaling that the pack is ready for deployment. The charger then transitions to a low-consumption maintenance mode, holding the correct potential to offset self-discharge without causing overcharging, cell swelling, or thermal stress.

Q4: With a heavy-duty 300W power output, how does this charger handle heat dissipation without an internal cooling fan?

A: Through engineered passive convection and high-efficiency thermal design. Unlike traditional loud chargers, this 10A charger features a 100% fanless, silent design. Henryuan employs a high-quality, high-strength plastic shell design, combined with advanced internal heat sinks and a unique external geometry to maximize heat dissipation area. This allows heat to be quickly and directly transferred to the shell. Coupled with an efficient switching circuit, waste heat is minimized. This charger relies entirely on natural air convection to maintain the optimal temperature range, completely eliminating fan noise and the risk of mechanical failure.

Q5: What are the distinct advantages of this fanless, passive-cooling design for industrial deployment?

• Zero Noise Pollution: Operates in complete, uncompromised silence (0dB), making it ideal for indoor, office, or overnight charging setups.

• Superior Durability & Dust Protection: Without a fan actively sucking in air, there is no risk of metallic dust, moisture, or debris building up inside the chassis. This drastically lowers maintenance costs and prevents premature circuit short-circuits in warehouses or workshops.

• Extended Service Life: Mechanical fans are typically the first component to fail in high-wattage hardware. This purely solid-state, passive thermal layout ensures the charger's lifespan naturally aligns with your multi-year equipment cycles.
